●产品特征：
Butt Hinge Steel Satin Brass Finish 100 lb Load Capacity With Holes 3 Holes per Leaf No Ligature Resistant 160 Degrees Range of Motion Orientation Non Handed 3 1/2 in Door Leaf Height 3 1/2 in Frame Leaf Height 3 1/2 in Door Leaf Width 3 1/2 in Frame Leaf Width 0.063 in Door Leaf Thickness 0.063 in Frame Leaf Thickness 1-3/8 in Required Door Thickness Plain Bearing Type Square Corners Included Hardware 3 hr Fire Rating - Door Hardware Features Reversible Hinges 1 Pair

●用途:
Bearing Type:Plain
Corners:Square
Fire Rating - Door Hardware:3 hr
Frame Leaf Thickness:0.087 in
Hardware:Included
Hinge Number:#1 Heavy Duty
Holes:With
Item:Butt Hinge
Ligature Resistant:No
Material:Steel
Orientation:Non Handed
Range of Motion:160 Degrees
Required Door Thickness:1-3/8 in
Door Leaf Height:3 1/2 in
Door Leaf Thickness:0.088 in
Door Leaf Width:3 1/2 in
Finish:Satin Brass
Frame Leaf Height:3 1/2 in
Frame Leaf Width:3 1/2 in
Holes per Leaf:3
Load Capacity:100.0 lb
Mounting:Full Mortise
Number of Wires:0
Pin Dia.:5/16 in
Pin Material:Steel
Pin Type:Removable
Standards:ANSI/BHMA
