●产品特征：
Chemical Metering Pump Discharge Connection Size 1/2 in Discharge Connection Type NPT Flow Rate (Maximum) 575.88 gpd Flow Rate (Minimum) 575.88 gpd Horsepower (Maximum) 11/32 hp Intake Connection Size 3/8 in Intake Connection Type Hose Media Temperature (Maximum) 160 Degrees F Nameplate Voltage 230V AC Number of Feeds 1 Pressure (Maximum) 125 psi Reproducibility +/-5.0 Percent Tubing Material Rubber Turn Down Ratio 10 1 Viscosity (Maximum) 2 000 cps

●用途:
cc/Min.:1514
Cord Length:Hardwired Installation Require
Flow Rate:0.40 gpm/1.50Lpm
Head and Fitting Material - Pu:316 Stainless Steel
Hz:60
Includes:Shim Kit
Item - Chemical Metering Pumps:Chemical Metering Pump
Number of Feeds:1
Pump RPM:42
Suction Lift:30 ft.
Turn Down Ratio - Pumps:10:1
Body Material:Aluminum
Chemical Metering Pump Type:Peristaltic
Flow Rate Output Control:Fixed
Height:20"
HP - Pumps:11/32
Length:10"
Max. Flow (gpd) - Pumps:575.88 gpd
Max. Pressure - Pumps:125 psi
Max. Viscosity - Pumps:2000 cP
Min. Flow Rate:575.88 gpd
Motor RPM:1700
Phase - Pumps:3
Reproducibility - Pumps:+/-5.0%
Seals and O-Rings - Pumps:EPDM/Buna-N
Self-Priming:Yes
Standards:UL
Tubing Material - Peristaltic :Rubber
Voltage - Pumps:230V AC
Width:12-1/2"
